Strange P3P behaviour after FW update.

Discussion in 'Pro/Adv Discussion' started by Luis Costa, Aug 5, 2015.

  1. Luis Costa

    Joined:
    Jul 17, 2015
    Messages:
    40
    Likes Received:
    2
    Last night, following the positive feedback here on the forum, I updated my P3P to the latest firmware, left the .bin file on the micro sd card, because I was expecting a new battery today.
    This morning, went to the usual place where I test, open space, no interference, no metal on the ground nor around the take off area...

    As soon as I started the motors, the left front one started rotating so fast it made the drone tremble.
    Also the app (android version......) showed no connection to the drone, never experienced that before.
    I lifted the aircraft a few feet of the ground, but it went down suddenly and I freaked out, landed immediatelly, restarted the whole process and it looked it was fine again.

    During flight, the gimbal suddenly stoped working properly, and the camera remained slightly tilted for the rest of the flight.

    Finnaly while I was packing the P3P, I noticed the tiny screw on the tip of the left front arm ( the one that shaked violently ) had losen itself a bit, and a gap was clearly visible in the structure.

    Question: has anyone ever experienced something like this before?!?
    One motor going nuts?

    Should I've calibrated the P3P after the FW update?
    On the status screen, it did not asked for calibration, was seemingly fine.

    I am now trying to find a torx t6 screwdriver to try and tighten the little screw, before it leads to more structural wear.

  2. ianwood

    ianwood Taco Wrangler
    Staff Member

    Joined:
    Jan 7, 2014
    Messages:
    4,932
    Likes Received:
    1,801
    Location:
    Lost Angeles
    Definitely tighten the screw! I would recommend full calibration of RC, IMU and compass after applying FW.

  3. Luis Costa

    Joined:
    Jul 17, 2015
    Messages:
    40
    Likes Received:
    2
    Could the shaking lose the screw?!?
    It was intense alright, but to that extension?

    I frequently calibrate the RC (wich imo is too simple, just pressing the sticks...), and the IMU check always says its fine.
    I don't even know how to calibrate it.
    As for the compass, I only did the initial calibration a month ago when I bought the P3P, and never touched it since.
    Always fly in the same area.

    Guess it's time for a compass calibration.

  4. pedrombracho

    Joined:
    Jul 19, 2015
    Messages:
    34
    Likes Received:
    9
    Location:
    Valencia, Venezuela
    This is a common advice. ALWAYS do a compass calibration BEFORE every flight. ALWAYS. Doesn't matter what the screen says. It doesn't hurt anyone!

  5. Raph

    Joined:
    May 18, 2015
    Messages:
    25
    Likes Received:
    4
    Seems to me a lot of people here don't ALWAYS recommend doing a compass calibration before a flight. My take is it's good to do when flying a new location, but if you're in the same general area and conditions (<50mi) you're better off not doing one. If I've had a few good flights id rather not risk messing the next one up because of a poor calibration.

    skyhighdiver and acherman like this.
  6. Luis Costa

    Joined:
    Jul 17, 2015
    Messages:
    40
    Likes Received:
    2
    What about the one crazed raging motor threatning to dismantle the drone?
    Anyone ever experienced something like that?

    Could it be because I left the firmware .bin file on the sd card?

  7. nhoover

    Joined:
    Dec 11, 2013
    Messages:
    851
    Likes Received:
    182
    Location:
    Los Gatos, California
    It's not my advice. If the compass is calibrated ok from a previous flight, and you haven't moved more than say 50 miles, it works fine without calibrating. I have done over 400 flights (not consecutively) with various Phantoms without calibrating - I only do it when I move a long way, probably 1 flight in 20 or 30. I've calibrated my P3P compass maybe 5 times in 75 flights - once was when I went to a different continent and again when I returned. All that without a hint of TBE or crooked flying like in the old days.

    If you are calibrated well from before and do it "just to be safe" but happen to be near some metal you didn't notice, then you would've been better off not calibrating.

    skyhighdiver likes this.
  8. jryser

    Joined:
    Aug 3, 2014
    Messages:
    328
    Likes Received:
    118
    Location:
    Indiana
    Not due to firmware bin file. You need that on to update all your batteries. As to the motor I can't see it but can't help but wonder about the screw. Also suggest IMU and gimbal cal as suggested above.


    Sent from my PT beating heart

  9. snerd

    Joined:
    May 5, 2015
    Messages:
    2,633
    Likes Received:
    1,585
    Location:
    Oklahoma
    From what I've read on here, that one motor spinning wildly, you may have an ESC going bad. Anyone more experienced with it than me have thoughts?

    Luis Costa likes this.
  10. BenDronePilot

    Joined:
    Dec 7, 2013
    Messages:
    1,204
    Likes Received:
    131
    Uhm.. No.

    bbfpv and skyhighdiver like this.
  11. JayB

    Joined:
    Apr 10, 2015
    Messages:
    282
    Likes Received:
    82
    Location:
    Nottingham UK
    After reading comments about calibrating the compass every flight I made the mistake of calibrating the compass near a lock that now I realise was full of rebar.....it would not calibrate and I had to find a safe place away from the Lock. I think your better off finding a field far away from any structures and calibrating there and then from what I have read you should be good for at least 100 mile radius from that point

  12. jephoto

    Joined:
    Jun 15, 2015
    Messages:
    555
    Likes Received:
    179
    Whenever I move to a different spot- even if 50-100 yds away I redo the compass calibrate ( I'm assuming you mean the GPS lock) so when I do RTH it will come to ME not 150-150' away.
    Yesterday shooting at the pier in the foreground here we first started near the middle of the pier- lots of cement & rebar- and my friends P3 took off and immediately was acting whacky and reeling like a drunk at closing time. Took a couple minutes to wrestle it back to where I could catch it. Didn't want to crash it in sand. ImageUploadedByPhantomPilots1438867611.211573.jpg

    We then moved over about 2 inches to the right on photo where there's an area of grass between the beach and the pier & calibrated correctly & both flew just fine.
    But later that morning he kept having severe tilt issues and had to do an Auto Gimbal adjustment several times that day to keep camera level.
    Don't know if 2 events are connected or not.
    But the bird does NOT like a lot of cement....

    Luis Costa likes this.
  13. Sky King

    Joined:
    Jul 19, 2015
    Messages:
    159
    Likes Received:
    66
    Which is why I try to do my (rare) compass calibrations either over asphalt (has no r-bar, or grassy areas.

  14. Luis Costa

    Joined:
    Jul 17, 2015
    Messages:
    40
    Likes Received:
    2
    After some research, I am inclined to think this may be the case.......
    Others have mentioned ESC errors after a firmware upgrade.
    There's a video on youtube of a Phantom ESC rotating slower than its peers, wich looks like the same issue I encountered yesterday.
    I will do some more testing to be "sure", since the app wasn't connected to the aircraft at the moment I turned on the motors.

    I have the P3P for a month now, 40 flights.
    Max distance 1200m, max altitude 300m.
    Had a crash (my fault mostly, but extreme bad luck and the app failure didnĀ“t help either) on my second day, third flight.

    As many have stated, when it works it is heaven!
    For someone that loves photography and video like I do, it's a dream come true!

    But...
    I think these things are still too unreliable, the android app is garbage (only works since I rolled back Google Play services, wich leaves my phone useless for a lot of apps), on two ocasions the P3P scared the hell out of me by not responding to RC input, drifting to the left, not obeying the forward command... Birds keep flying over the aircraft and they will eventually bring it down...
    Twice it almost crashed during landing (imo the most dangerous step of all) due to a slight breeze.

    About the wind, I do not feel safe when it exceeds a mere 10km/hour, wich is almost all the time.

    If this in fact is a bad ESC, I'll probably quit this hobby, since it's far too costly and potentially harmfull to others in case of one of the many technical failures that plague these products.


    Great picture, Jeff!

  15. JayB

    Joined:
    Apr 10, 2015
    Messages:
    282
    Likes Received:
    82
    Location:
    Nottingham UK
    No you are talking about the home point which is automatically set when you switch the P3 on and subsequently you can reset it if you move. I am talking about the compass calibration which you are required to perform the DJI spin.


  16. bbfpv

    Joined:
    Feb 3, 2015
    Messages:
    3,751
    Likes Received:
    1,093
    Location:
    Long Island, NY
    I hope not.

    unclejas likes this.
  17. F6Rider

    Joined:
    Feb 5, 2014
    Messages:
    1,126
    Likes Received:
    346
    Location:
    Foothills Of The Sierra's, California
    The only compass calibration I do is after a firmware update or a new location >100 miles away, never had one compass issue, I sure don't want to introduce a problem that doesn't exist.

    BenDronePilot and bbfpv like this.
  18. snerd

    Joined:
    May 5, 2015
    Messages:
    2,633
    Likes Received:
    1,585
    Location:
    Oklahoma
    Ditto.

  19. jadebox

    Joined:
    Nov 20, 2013
    Messages:
    490
    Likes Received:
    51
    Location:
    Oviedo, FL
    The new firmware did change something to do with ESCs. According to the release notes, a motor will now shut down if something impedes the rotation of the propeller. It doesn't seem like that could cause a motor to run too fast, though, even if there was a problem with the motor or ESC.

    Was the loose screw near the motor that acted up? Maybe the loose screw made the motor act up or appear to act up amd it was the only problem.

    -- Roger

  20. Luis Costa

    Joined:
    Jul 17, 2015
    Messages:
    40
    Likes Received:
    2
    That's interesting, the fact the new firmware did mess with the ESC.
    Since the crash, I spend a good amount of time visually inspecting the quad, before and after every flight.
    I am pretty sure it was the vibration caused by the uncontrolled spinning of that particular motor that led to the screw getting lose.
    I will be getting my hands on a T6 and T8 tonight, and see if it can be tightened back.

    Tomorrow, more ground testing with the motors on, IMU checking and a compass calibration.
    There's nothing more to do, I guess.......

    I don't think I'll be flying over property or people anytime soon.
