How to Update Tx-Power with Magic Power v5.0

You are welcome.
Not recommended for removing the telnet because RC send tx-power and coverage setting to AC via telnet, the other feature is if you want to change channel also be done via telnet.
If you are worried, the wifi password that should be replaced.
so, this is telnet service inside the RC we are talking about.
am i correct papatita?

Sent from my SCL23 using PhantomPilots mobile app

  • Like
Reactions: kid joe
You are welcome.
Not recommended for removing the telnet because RC send tx-power and coverage setting to AC via telnet, the other feature is if you want to change channel also be done via telnet.
If you are worried, the wifi password that should be replaced.
tnx for the reply... i mean the telnet app installed on my phone.

Hi Papatita, I selected 27 dBm but didn't chose anything on optional setting. It works but it showed the following results. I had made these steps twice. Is that meant I have successfully changed to 27 dBm? Anything went wrong? Thanks for your help.


10:58 Log Filename: log201610170039.txt
10:58
10:58 ============================================
10:58 Restart your RC & Aircraft and Enjoy New Mod
10:58 ============================================
10:58
10:58 Credit to: Ojcze Nasz, SingLag, Argonaise & www.phantompilots.com
Disconnected.
Disconnecting.
10:57 wlan0 ESSID: "PHANTOM3_0b5bd9"
Access Point: 60:60:1F:01:02:03
Mode: Master Channel: 2 (2.417 GHz)
Tx-Power: 24 dBm Link Quality: 70/70
Signal: -35 dBm Noise: -95 dBm
Bit Rate: 101.1 MBit/s
Encryption: WPA2 PSK (CCMP)
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

wlan0.sta1 ESSID: unknown
Access Point: 00:00:00:00:00:00
Mode: Master (VLAN) Channel: 2 (2.417 GHz)
Tx-Power: 24 dBm Link Quality: 70/70
Signal: -18 dBm Noise: -95 dBm
Bit Rate: 130.0 MBit/s
Encryption: none
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

/ #
10:57 iwinfo

10:57



BusyBox v1.22.1 (2015-11-16 16:28:58 CST) built-in shell (ash)
Enter 'help' for a list of built-in commands.

/ # iw reg set BO
/ # iw dev wlan0 set txpower limit 2400
/ #
10:57 iwinfo
10:56 iw dev wlan0 set txpower limit 2400
10:56 iw reg set BO
Connected.
Connecting to 192.168.1.1.
Disconnected.
Disconnecting.
10:56 ==================
10:55 File upload OKE
10:55 Checking file ...
10:55 Update djiled.sh on Aircraft
10:55 Final process ...
10:55 hmod 775 /sbin/watchlog.sh
/ #
10:54 c
10:54



BusyBox v1.22.1 (2015-11-16 16:28:58 CST) built-in shell (ash)
Enter 'help' for a list of built-in commands.

/ #
10:54 chmod 775 /sbin/watchlog.sh
Connected.
Connecting to 192.168.1.2.
Disconnected.
Disconnecting.
10:54 File upload OKE
10:54 Checking file ...
10:54 Update djiled.sh on RC
10:53 / #
10:53 Final process ...
10:53 hmod 775 /sbin/watchlog.sh

10:53 c
10:53 chmod 775 /sbin/watchlog.sh
10:52 wlan0 ESSID: "PHANTOM3_0b5bd9"
Access Point: 60:60:1F:01:02:03
Mode: Master Channel: 2 (2.417 GHz)
Tx-Power: 27 dBm Link Quality: 70/70
Signal: -33 dBm Noise: -95 dBm
Bit Rate: 57.7 MBit/s
Encryption: WPA2 PSK (CCMP)
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

wlan0.sta1 ESSID: unknown
Access Point: 00:00:00:00:00:00
Mode: Master (VLAN) Channel: 2 (2.417 GHz)
Tx-Power: 27 dBm Link Quality: 70/70
Signal: -15 dBm Noise: -95 dBm
Bit Rate: 43.3 MBit/s
Encryption: none
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

/ #
10:52 winfo

10:52 i
10:52 iwinfo
10:51 BusyBox v1.22.1 (2015-11-16 16:28:58 CST) built-in shell (ash)
Enter 'help' for a list of built-in commands.

/ #
10:51 ==================
10:51 Telnet ready ...
Connected.
Connecting to 192.168.1.1.
10:51 Aircraft Ready ...
10:51 RC Ready ...
10:49 File upload OKE
10:49 Checking file ...
10:49 Upload watchlog.sh to aircraft
10:48 File upload OKE
10:48 Checking file ...
10:48 Upload watchlog.sh to RC
10:47 File upload OKE
10:47 Checking file ...
10:47 Configure Telnet to Aircraft
10:46 File upload OKE
10:46 Checking file ...
10:46 Configure Telnet to RC
10:45 Aircraft Ready ...
10:45 RC Ready ...
Disconnected.
Disconnecting.
10:45 Select Menu: Patch with Magic Power

same with me. . .

here is my flightlog recorded by the dji.go apps. they are separated into 9 flightlogs which are actually came from a single flight with 2times auto RTH due to lost signal. although it could reach the same distance as previous version, but i hate to say that previous test using v.5.0 is better (more solid fpv and logs) than this v.5.1.

i am gonna test it again tomorrow for sure. . .



and this is video result inside the DJI_RECORD folder. they are 4 videos for one flight.



Sent from my SCL23 using PhantomPilots mobile app
may i know when was this 5.1 version released & uploaded? i got the 5.0 version last week (oct. 13, 2016). is that the latest file?

yes this is correct and successful.


Thank you PapaTita. But I am wondering why it still shows 24 dBm at 10:57 position:

Tx-Power: 24 dBm Link Quality: 70/70
Signal: -35 dBm Noise: -95 dBm
.............
.............
Tx-Power: 24 dBm Link Quality: 70/70
Signal: -18 dBm Noise: -95 dBm

Thank you PapaTita. But I am wondering why it still shows 24 dBm at 10:57 position:

Tx-Power: 24 dBm Link Quality: 70/70
Signal: -35 dBm Noise: -95 dBm
.............
.............
Tx-Power: 24 dBm Link Quality: 70/70
Signal: -18 dBm Noise: -95 dBm
Indeed, default tx-power for v5 is 24dBm

Sent from my Redmi Note 2 using PhantomPilots mobile app

Indeed, default tx-power for v5 is 24dBm

Sent from my Redmi Note 2 using PhantomPilots mobile app
sometimes, papatita just didn't read the question carefully. . . if i may to make it straight om paps, he did choose the option 27dBm but why the result is still 24dBm.

i know you might need an assistant to help you answer questions. . . .[emoji38]seem you're exhausted during late works paps. . . . [emoji12] [emoji16]
Thank you PapaTita. But I am wondering why it still shows 24 dBm at 10:57 position:

Tx-Power: 24 dBm Link Quality: 70/70
Signal: -35 dBm Noise: -95 dBm
.............
.............
Tx-Power: 24 dBm Link Quality: 70/70
Signal: -18 dBm Noise: -95 dBm

Hi Papatita, I selected 27 dBm but didn't chose anything on optional setting. It works but it showed the following results. I had made these steps twice. Is that meant I have successfully changed to 27 dBm? Anything went wrong? Thanks for your help.


10:58 Log Filename: log201610170039.txt
10:58
10:58 ============================================
10:58 Restart your RC & Aircraft and Enjoy New Mod
10:58 ============================================
10:58
10:58 Credit to: Ojcze Nasz, SingLag, Argonaise & www.phantompilots.com
Disconnected.
Disconnecting.
10:57 wlan0 ESSID: "PHANTOM3_0b5bd9"
Access Point: 60:60:1F:01:02:03
Mode: Master Channel: 2 (2.417 GHz)
Tx-Power: 24 dBm Link Quality: 70/70
Signal: -35 dBm Noise: -95 dBm
Bit Rate: 101.1 MBit/s
Encryption: WPA2 PSK (CCMP)
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

wlan0.sta1 ESSID: unknown
Access Point: 00:00:00:00:00:00
Mode: Master (VLAN) Channel: 2 (2.417 GHz)
Tx-Power: 24 dBm Link Quality: 70/70
Signal: -18 dBm Noise: -95 dBm
Bit Rate: 130.0 MBit/s
Encryption: none
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

/ #
10:57 iwinfo

10:57



BusyBox v1.22.1 (2015-11-16 16:28:58 CST) built-in shell (ash)
Enter 'help' for a list of built-in commands.

/ # iw reg set BO
/ # iw dev wlan0 set txpower limit 2400
/ #
10:57 iwinfo
10:56 iw dev wlan0 set txpower limit 2400
10:56 iw reg set BO
Connected.
Connecting to 192.168.1.1.
Disconnected.
Disconnecting.
10:56 ==================
10:55 File upload OKE
10:55 Checking file ...
10:55 Update djiled.sh on Aircraft
10:55 Final process ...
10:55 hmod 775 /sbin/watchlog.sh
/ #
10:54 c
10:54



BusyBox v1.22.1 (2015-11-16 16:28:58 CST) built-in shell (ash)
Enter 'help' for a list of built-in commands.

/ #
10:54 chmod 775 /sbin/watchlog.sh
Connected.
Connecting to 192.168.1.2.
Disconnected.
Disconnecting.
10:54 File upload OKE
10:54 Checking file ...
10:54 Update djiled.sh on RC
10:53 / #
10:53 Final process ...
10:53 hmod 775 /sbin/watchlog.sh

10:53 c
10:53 chmod 775 /sbin/watchlog.sh
10:52 wlan0 ESSID: "PHANTOM3_0b5bd9"
Access Point: 60:60:1F:01:02:03
Mode: Master Channel: 2 (2.417 GHz)
Tx-Power: 27 dBm Link Quality: 70/70
Signal: -33 dBm Noise: -95 dBm
Bit Rate: 57.7 MBit/s
Encryption: WPA2 PSK (CCMP)
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

wlan0.sta1 ESSID: unknown
Access Point: 00:00:00:00:00:00
Mode: Master (VLAN) Channel: 2 (2.417 GHz)
Tx-Power: 27 dBm Link Quality: 70/70
Signal: -15 dBm Noise: -95 dBm
Bit Rate: 43.3 MBit/s
Encryption: none
Type: nl80211 HW Mode(s): 802.11abgn
Hardware: unknown [Generic MAC80211]
TX power offset: unknown
Frequency offset: unknown
Supports VAPs: yes PHY name: phy0

/ #
10:52 winfo

10:52 i
10:52 iwinfo
10:51 BusyBox v1.22.1 (2015-11-16 16:28:58 CST) built-in shell (ash)
Enter 'help' for a list of built-in commands.

/ #
10:51 ==================
10:51 Telnet ready ...
Connected.
Connecting to 192.168.1.1.
10:51 Aircraft Ready ...
10:51 RC Ready ...
10:49 File upload OKE
10:49 Checking file ...
10:49 Upload watchlog.sh to aircraft
10:48 File upload OKE
10:48 Checking file ...
10:48 Upload watchlog.sh to RC
10:47 File upload OKE
10:47 Checking file ...
10:47 Configure Telnet to Aircraft
10:46 File upload OKE
10:46 Checking file ...
10:46 Configure Telnet to RC
10:45 Aircraft Ready ...
10:45 RC Ready ...
Disconnected.
Disconnecting.
10:45 Select Menu: Patch with Magic Power


Sent from my SCL23 using PhantomPilots mobile app

I'm sure that PapaTita done a great work but i still have a problem.

In the last 2/3 days i've done some tests trying to trace every condition but the result seems always the same: i cannot improve the distance range of video/telemetry of my P3 standard.

First of all i've found a good place to do my tests not closer than 300 meters from the nearest house and i have no strange antennas nearby. Furthermore the WiFi analyzer on my cell phone tell me that there are no others signals on 2.4GHz band.

In this place i've tested the following configurations:
  1. 5.0 mod (24dBm) and fw release 1.5.7+
  2. NO mod and fw release 1.5.7+
  3. NO mod and fw release 1.6.80
  4. 5.0 mod (24dBm) and fw release 1.6.80
In all these test i lost the video/telemetry signal at about 150/180m of distance and 70/80m hight flying both in the direction of the countryside or in the opposite direction towards the nearest houses.

The strange thing is that i can see a signal improvement using a WiFi analyzer on my cell phone when i apply the PapaTita's mod, but this improvement seems to have no practical effect in flight.

I'm a bit sad :(:(
What can i try more?
Any idea???

I'm sure that PapaTita done a great work but i still have a problem.

In the last 2/3 days i've done some tests trying to trace every condition but the result seems always the same: i cannot improve the distance range of video/telemetry of my P3 standard.

First of all i've found a good place to do my tests not closer than 300 meters from the nearest house and i have no strange antennas nearby. Furthermore the WiFi analyzer on my cell phone tell me that there are no others signals on 2.4GHz band.

In this place i've tested the following configurations:
  1. 5.0 mod (24dBm) and fw release 1.5.7+
  2. NO mod and fw release 1.5.7+
  3. NO mod and fw release 1.6.80
  4. 5.0 mod (24dBm) and fw release 1.6.80
In all these test i lost the video/telemetry signal at about 150/180m of distance and 70/80m hight flying both in the direction of the countryside or in the opposite direction towards the nearest houses.

The strange thing is that i can see a signal improvement using a WiFi analyzer on my cell phone when i apply the PapaTita's mod, but this improvement seems to have no practical effect in flight.

I'm a bit sad :(:(
What can i try more?
Any idea???
Hardware issue ??

Hardware issue ??

i guess so. . .

I'm sure that PapaTita done a great work but i still have a problem.

In the last 2/3 days i've done some tests trying to trace every condition but the result seems always the same: i cannot improve the distance range of video/telemetry of my P3 standard.

First of all i've found a good place to do my tests not closer than 300 meters from the nearest house and i have no strange antennas nearby. Furthermore the WiFi analyzer on my cell phone tell me that there are no others signals on 2.4GHz band.

In this place i've tested the following configurations:
  1. 5.0 mod (24dBm) and fw release 1.5.7+
  2. NO mod and fw release 1.5.7+
  3. NO mod and fw release 1.6.80
  4. 5.0 mod (24dBm) and fw release 1.6.80
In all these test i lost the video/telemetry signal at about 150/180m of distance and 70/80m hight flying both in the direction of the countryside or in the opposite direction towards the nearest houses.

The strange thing is that i can see a signal improvement using a WiFi analyzer on my cell phone when i apply the PapaTita's mod, but this improvement seems to have no practical effect in flight.

I'm a bit sad :(:(
What can i try more?
Any idea???

IWILZ, you should check the antenna connection inside the RC. regarding your description above, i belive it is FCC moded already. but the lack of proper antenna connection could cause this. i have experienced it once and had it analyzed by the flyxxx.dat, i can see that the AC intermittently lost signal in very short range under 100meters. it was happened when i tried to mod my antenna but i guess i pick the wrong frequency. . . . . and now i put back the stock antenna while waiting for 5.8ghz antenna on its way, . . .

Sent from my SCL23 using PhantomPilots mobile app

  • Like
Reactions: IWILZ
What means sorry?
How did you analyzed the flight log please?

FCC mod : This is the whole story of this thread we are talking about. Please read first post writen by papatita on page one.
Analyze FlightLog : Download the FLYxxx.DAT file from the phantom's internal memory. Convert into CSV format using DATCON. Paste it on the flight video as HUD / dashboard info using DASHWARE, so we can read any values we want during the flight according to the video. See this after 00:55 --->
To view this content we will need your consent to set third party cookies.
For more detailed information, see our cookies page.

  • Like
Reactions: IWILZ

Recent Posts

Members online

Forum statistics

Threads
143,066
Messages
1,467,352
Members
104,933
Latest member
mactechnic
