Bad quality image on the upper left side

Discussion in 'Pro/Adv Discussion' started by marciano, Aug 30, 2015.

  1. marciano

    Joined:
    Oct 9, 2013
    Messages:
    81
    Likes Received:
    1
    This is a new P3P. Is that a regular issue? DJI_0058b.jpg

  2. Garrie

    Joined:
    Jul 31, 2015
    Messages:
    326
    Likes Received:
    127
    Location:
    Singapore
    Lens sharpness falls from the centre to the corner edges. It's nothing special nor new. Even very expensive lenses used in photography have different Center and edge performance.

  3. marciano

    Joined:
    Oct 9, 2013
    Messages:
    81
    Likes Received:
    1
    But this is very noticeable, unacceptable!

  4. Garrie

    Joined:
    Jul 31, 2015
    Messages:
    326
    Likes Received:
    127
    Location:
    Singapore
    Does it appear in all the photos you take? Or just this?

  5. marciano

    Joined:
    Oct 9, 2013
    Messages:
    81
    Likes Received:
    1
    In all the photos and video frames

  6. Garrie

    Joined:
    Jul 31, 2015
    Messages:
    326
    Likes Received:
    127
    Location:
    Singapore
    Here is a photo which I took recently.


    The image seems decent from Center to the edges.

  7. BigKenny

    Joined:
    Jul 13, 2015
    Messages:
    77
    Likes Received:
    20
    Location:
    Minneapolis
    Where is this?

  8. marciano

    Joined:
    Oct 9, 2013
    Messages:
    81
    Likes Received:
    1
    I agree but mine does not. There's no need to enlarge it or see it in real size to see the difference.
    It seems the lens has not been perfectly assembled, I have to contact dji support

  9. Garrie

    Joined:
    Jul 31, 2015
    Messages:
    326
    Likes Received:
    127
    Location:
    Singapore
    Singapore

  10. 4wd

    4wd

    Joined:
    Mar 31, 2014
    Messages:
    2,532
    Likes Received:
    421
    Location:
    North York Moors
    It looks like the whole left side is rather soft presumably not focusing properly.
    If it is almost new I would ask about an exchange, it has probably not been assembled perfectly accurate.
    There were some cases of the Vision Plus shipping with a visibly misaligned component in the camera.
    If bought from a dealer this might all go smoothly, if direct from DJI you will have a long period without it I fear.

    You *might* consider swapping the camera/gimbal yourself.
    Sometimes this is the simplest option but will cost you.
    However the old one might do as a spare should there be any mishap.

    You might even be able to see something mis-aligned inside through the lens, unscrewing the filter barrel could make it easier to see.

    marciano likes this.
  11. marciano

    Joined:
    Oct 9, 2013
    Messages:
    81
    Likes Received:
    1
    It is one week old. I didn't realize that earlier because I was learning about the drone and its app features and settings.
    I could unscrew the front ring, smoothly with a rubber band, but I didn't see anything wrong. Misalign would be imperceptible
